    Home / Taps / Machine taps / 3660 - Machine tap with straight flutes and spiral point

    3660 - Machine tap with straight flutes and spiral point

    Code: 041535262050000
    3660 - Machine tap with straight flutes and spiral point
    from €30,47 from €25,18 excl. VAT

    Choose variant

    Catalogue number: 3660

    Machine tap with straight flutes and spiral point, metric and metric fine, DIN 376, DIN 374, TiN coated, suitable for case hardened and nitriding steels, stainless steels with stength up to 1000 N/mm2, unalloyed copper and long chipping copper alloys.



    Thread M: ISO Metric coarse threadThread M:   ISO Metric coarse thread

    Thread MF: ISO Metric fine threadThread MF:   ISO Metric fine thread

    Profile sketch: 60°Profile sketch:   60°

    Thread standard: DIN 13Thread standard:   DIN 13

    Type VA: Tap for stainless steelsType VA:   Tap for stainless steels

    Tap material: Super high speed steelTap material:   Super high speed steel

    Coating: Titanium nitride coatingCoating:   Titanium nitride coating

    Tap standard: DIN 376Tap standard:   DIN 376

    Tap standard: DIN 374Tap standard:   DIN 374

    Thread tolerance: ISO 2 - 6HThread tolerance:   ISO 2 - 6H

    Chamfer B: Length 3,5-6 pitchChamfer B:   Length 3,5-6 pitch

    Hole type: Through hole (thread length L > 1,5xd1)Hole type:   Through hole (thread length L > 1,5xd1)


    Detailed information

    Variant: M 3x0,5 6H
    In stock (10 pcs) | 041535262030000
    €31,44
    €25,98 excl. VAT
    Variant: M 4x0,7 6H
    In stock (>10 pcs) | 041535262040000
    €31,88
    €26,35 excl. VAT
    Variant: M 5x0,8 6H
    In stock (>10 pcs) | 041535262050000
    €30,47
    €25,18 excl. VAT
    Variant: M 6x0,75 6H
    In stock (>10 pcs) | 041535462068000
    €40,72
    €33,65 excl. VAT
    Variant: M 6x1 6H
    In stock (>10 pcs) | 041535262060000
    €31,44
    €25,98 excl. VAT
    Variant: M 8x0,75 6H
    In stock (>10 pcs) | 041535462088000
    €45,28
    €37,42 excl. VAT
    Variant: M 8x1 6H
    In stock (>10 pcs) | 041535462087000
    €41,09
    €33,96 excl. VAT
    Variant: M 8x1,25 6H
    In stock (>10 pcs) | 041535262080000
    €33,38
    €27,59 excl. VAT
    Variant: M 10x1 6H
    In stock (>10 pcs) | 041535462107000
    €42,97
    €35,51 excl. VAT
    Variant: M 10x1,5 6H
    In stock (>10 pcs) | 041535262100000
    €38,16
    €31,54 excl. VAT
    Variant: M 12x1 6H
    In stock (>10 pcs) | 041535462127000
    €49,92
    €41,26 excl. VAT
    Variant: M 12x1,5 6H
    In stock (>10 pcs) | 041535462125000
    €47,08
    €38,91 excl. VAT
    Variant: M 12x1,75 6H
    In stock (>10 pcs) | 041535262120000
    €47,01
    €38,85 excl. VAT
    Variant: M 14x1,5 6H
    In stock (>10 pcs) | 041535462145000
    €62,71
    €51,83 excl. VAT
    Variant: M 14x2 6H
    In stock (>10 pcs) | 041535262140000
    €59,13
    €48,87 excl. VAT
    Variant: M 16x1,5 6H
    In stock (>10 pcs) | 041535462165000
    €71,24
    €58,88 excl. VAT
    Variant: M 16x2 6H
    In stock (>10 pcs) | 041535262160000
    €61,75
    €51,03 excl. VAT
    Variant: M 18x1,5 6H
    In stock (5 pcs) | 041535462185000
    €88,48
    €73,12 excl. VAT
    Variant: M 18x2,5 6H
    In stock (>10 pcs) | 041535262180000
    €92,66
    €76,58 excl. VAT
    Variant: M 20x1,5 6H
    In stock (10 pcs) | 041535462205000
    €99,16
    €81,95 excl. VAT
    Variant: M 20x2,5 6H
    In stock (>10 pcs) | 041535262200000
    €95,72
    €79,11 excl. VAT
    Variant: M 22x2,5 6H
    In stock (>10 pcs) | 041535262220000
    €138,23
    €114,24 excl. VAT
    Variant: M 24x3 6H
    In stock (>10 pcs) | 041535262240000
    €129,94
    €107,39 excl. VAT
    Variant: M 27x3 6H
    In stock (6 pcs) | 041535262270000
    €173,65
    €143,51 excl. VAT
    Variant: M 30x3,5 6H
    In stock (>10 pcs) | 041535262300000
    €210,01
    €173,56 excl. VAT

    Product detailed description

    Catalogue number: 3660

    Machine tap with straight flutes and spiral point, metric and metric fine, DIN 376, DIN 374, TiN coated, suitable for case hardened and nitriding steels, stainless steels with stength up to 1000 N/mm2, unalloyed copper and long chipping copper alloys.



    Features:

    Thread M: ISO Metric coarse threadThread M:   ISO Metric coarse thread

    Thread MF: ISO Metric fine threadThread MF:   ISO Metric fine thread

    Profile sketch: 60°Profile sketch:   60°

    Thread standard: DIN 13Thread standard:   DIN 13

    Type VA: Tap for stainless steelsType VA:   Tap for stainless steels

    Tap material: Super high speed steelTap material:   Super high speed steel

    Coating: Titanium nitride coatingCoating:   Titanium nitride coating

    Tap standard: DIN 376Tap standard:   DIN 376

    Tap standard: DIN 374Tap standard:   DIN 374

    Thread tolerance: ISO 2 - 6HThread tolerance:   ISO 2 - 6H

    Chamfer B: Length 3,5-6 pitchChamfer B:   Length 3,5-6 pitch

    Hole type: Through hole (thread length L > 1,5xd1)Hole type:   Through hole (thread length L > 1,5xd1)




    Machined materials:

    GroupMachined materialCutting speed
    P3.1Case hardened and nitriding steels <1200N/mm24-8
    M5.1Stainless steels 450-800N/mm28-12
    M5.2Stainless steels 600-1000N/mm25-8
    N9.1Pure copper8-12
    N10.2Long chipping copper alloys10-15



    Dimensions:

    3660: kreslenka
    d1Ptoll1l2d2ahole
    M 30,56H5692,2-2,5
    M 40,76H63122,82,13,3
    M 50,86H70133,52,74,2
    M 60,756H80154,53,45,2
    M 616H80154,53,45
    M 816H901864,97
    M 81,256H901864,96,8
    M 80,756H801564,97,2
    M 101,56H1002075,58,5
    M 1016H902075,59
    M 121,756H110239710,2
    M 121,56H100219710,5
    M 1216H100219711
    M 141,56H1002111912,5
    M 1426H1102511912
    M 1626H1102512914
    M 161,56H1002112914,5
    M 182,56H12530141115,5
    M 181,56H11024141116,5
    M 201,56H12524161218,5
    M 202,56H14030161217,5
    M 222,56H140301814,519,5
    M 2436H160361814,521
    M 2736H16036201624
    M 303,56H18040221826,5

    Additional parameters

    Category: Machine taps
    Coating: TiN
    Hole type: through hole (thread length L > 1,5xd1), through hole (thread length L < 1,5xd1)
    Machined material: Stainless steels 450-800N/mm2, Stainless steels 600-1000N/mm2, Long chipping copper alloys, Case hardened and nitriding steels <1200N/mm2, Pure copper
    Product line: NAREX Zdanice Product Line
    Standard: DIN 374, DIN 376
    Thread type: Metric ISO Thread, Metric ISO Fine Thread
    Tolerance: 6H
